With it’s unique design and added strength, 9TORC Manual torque multipliers are more productive, durable, less-weight and easy to use as compared to the conventional designs in the market. Covering almost upto 47500Nm torque capacity, various model are available.
|
MANUAL TORQUE MULTIPLIER |
MAXIMUM OUTPUT TORQUE |
ESTIMATED CAPACITY(S. QUALITY) |
MULTIPLI-CATION FACTOR |
FEMALE INPUT SQUARE |
MALE OUTPUT SQUARE |
Weight |
|||
|
MODEL NO |
lbft |
Nm. |
Kgf.m |
In. |
mm |
|
In. |
In |
Kg |
|
9TM-1 |
1250 |
1700 |
170 |
1.1/8 |
27 |
5 |
1/2 |
3/4 |
4.5 |
|
9TM-2 |
1250 |
1700 |
170 |
1.1/8 |
27 |
5 |
3/4 |
1 |
5 |
|
9TM-2/25 |
1250 |
1700 |
170 |
1.1/8 |
27 |
25 |
1/2 |
1 |
7 |
|
9TM-5 |
2000 |
2700 |
275 |
1.3/8 |
36 |
5 |
3/4 |
1 |
11 |
|
9TM-5/25 |
2000 |
2700 |
275 |
1.3/8 |
36 |
25 |
1/2 |
1 |
11 |
|
9TM-6 |
2500 |
3400 |
345 |
1.1/2 |
38 |
5 |
3/4 |
1.1/2 |
8.5 |
|
9TM-6/25 |
2500 |
3400 |
345 |
1.1/2 |
38 |
25 |
1/2 |
1.1/2 |
11.5 |
|
9TM-7 |
4500 |
6000 |
622 |
1.7/8 |
48 |
5 |
3/4 |
1.1/2 |
18 |
|
9TM-7/25 |
4500 |
6000 |
622 |
1.7/8 |
48 |
25 |
1/2 |
1.1/2 |
22 |
|
9TM-9/25 |
7000 |
9500 |
965 |
2.1/4 |
56 |
25 |
3/4 |
1.1/2 |
33 |
|
9TM-9/125 |
7000 |
9500 |
965 |
2.1/4 |
56 |
125 |
1/2 |
1.1/2 |
35.5 |
|
9TM-11/25 |
12500 |
17000 |
1735 |
3.3/4 |
95 |
25 |
3/4 |
2.1/2 |
52 |
|
9TM-11/125 |
12500 |
17000 |
1735 |
3.3/4 |
95 |
125 |
1/2 |
2.1/2 |
57 |
|
9TM-13/125 |
35000 |
47500 |
4845 |
4.1/2 |
115 |
125 |
3/4 |
2.1/2 |
80 |
|
MODEL NO. |
Gear Ratio |
Torque Capacity Max |
Input Drive (A) |
Output Drive (B) |
Suitable for Bolt Size |
|||
|
|
|
Ft.lbs |
Nm |
|
|
Thd. Size |
A/F |
|
|
9TSM:15 |
4.5:1 |
1000 |
1355 |
3/4" |
1" |
M16-M27 |
24-41 |
|
|
9TSM:25 |
12:1 |
1350 |
1630 |
3/4" |
1" |
M20-M30 |
30-46 |
|
|
9TSM:35 |
15:1 |
2125 |
2880 |
3/4" |
1" |
M20-M36 |
30-55 |
|
|
9TSM:40 |
15:1 |
2360 |
3200 |
3/4" |
1.1/2" |
M20-M39 |
30-60 |
|
|
9TSM:65 |
21:1 |
3660 |
4960 |
3/4" |
1.1/2" |
M27-M42 |
41-65 |
|
|
9TSM:90 |
40:1 |
5075 |
6880 |
3/4" |
1.1/2" |
M33-48 |
50-75 |
|
To get the Latest quote, Contact Us.
*NOTE-Product can be customized as per client’s requirements, mail your details to info@torquingtools.com© 9 Torc | Promoted & Maintained by ITology
